Introducing our high-quality 2.54mm pitch, 40-pin male straight header strip. Constructed with an insulator material of PBT with UL94V-0 certification, it ensures a safe and durable connection for your electronics projects. The brass contact material and plating options of Ni, Au, or Sn provide reliable conductivity and corrosion resistance.
Our header strip has a contact resistance of 20mΩ maximum and an insulation resistance of 1000MΩ minimum, ensuring high performance and a strong connection. With a current rating of 1.5A and an operating voltage of 250V AC, it is suitable for a wide range of applications.
Operating within a temperature range of -40°C to +105°C and able to withstand a test voltage of 500V AC, our header strip is designed to be robust and reliable. It comes in polybag packing, making it easy to store and use when needed. Choose our 40-pin female straight header strip for your next project and experience the difference in quality and performance.
Then why wait? To see the difference it can make in your electronics projects, order your 1×40 pin male Single Row Through-hole Header Strip right away.
