Trinity Touch TT-IMRB-08024D2S-C-RL(G) Relay card 8CH 1CO
-37%
EXPLORE 3D MODEL
VIEW IN 3D
Trinity Touch TT-IMRB-08024D2S-C-RL(G) Relay card 8CH 1CO
Original price was: ₹1,530.00.₹960.00Current price is: ₹960.00. (Including. of GST 18%)
Original price was: ₹1,530.00.₹960.00Current price is: ₹960.00. (Including. of GST 18%)
GST Credit of
*₹
is available on this product. Know More
In stock
Totals
x
Secure transaction
FEATURES & SPECIFICATIONS
| Parameter | Value | Notes |
|---|---|---|
| Number of Channels | 8 | Eight independent relay switches |
| Relay Type | Electromechanical (1CO) | Single Changeover (1 Form C) |
| Coil Voltage | 24V DC | Voltage required to activate the relay coils |
| Contact Rating | 5A @ 250V AC / 30V DC | Max load per channel (resistive) |
| Input Control Signal | 24V DC | Compatible with PLCs and industrial controllers |
| Protection | Freewheeling diode across relay coil | Prevents voltage spikes for circuit protection |
| Indication | LED for each relay | Shows relay activation status |
| Isolation | High-voltage isolation | Prevents interference between control and load circuits |
| Mounting | DIN 35 rail mount | Easy installation in control panels |
| Housing Color | Green / Black | Available in different color options |
| Operating Temperature | -40°C to +85°C | Suitable for harsh environments |
| Dimensions | Compact | Designed for space efficiency |
The Trinity Touch TT-IMRB-08024D2S-C-RL(G) is an 8-channel relay card designed for industrial automation, process control, and electrical switching applications. Each of the eight independent relay channels features single changeover (1CO) contacts, making it ideal for switching AC and DC loads. With a 24V DC coil voltage, it integrates seamlessly into industrial control panels, PLCs, and automation systems.
The relay board features LED indicators for each channel, providing real-time status monitoring. Additionally, freewheeling diodes are included across the relay coils to prevent voltage spikes, enhancing system safety and longevity. The module supports DIN 35 rail mounting, ensuring easy installation in standard industrial enclosures.
Built with high-quality components, this relay board offers reliable performance in challenging environments. It is perfect for switching motors, solenoids, heaters, and other electrical loads in industrial control systems.
